Drive Test Data Visualization

The latest solution in Systemics portfolio is the recently developed and introduced visualization portal engine for the measurement data (other network data could be integrated in the future). The use of this new tool for analysis and the visualization of the data, together with the user-interactive filtering and data manipulation offered by the portal solution will speed up the process of problem identification and troubleshooting

  • interactive access to data in order to prepare reporting and analyze results
  • geolocation of KPI and events on the maps
  • various presentations of measurement data and quality KPIs collected in measurement projects
  • real-time operations and filtering with various parameters or using a map selection tool
  • automatically recalculated content according to the selection and filtering applied
  • the ability to define new KPIs
  • automatic generation of various types of reports

This solution will be used by Systemics engineering staff in the process of the service delivery. It could also be made available to customer staff to provide them with customized access to the data or as a customized information portal. An example of such use can be found at

The solution covers 2G (GSM), 3G (UMTS, HSDPA, HSPA, HSPA DC), 4G (LTE, LTE-A, LTE CA, VoLTE) and is ready for future use in 5G (SA, Non-SA, IoT).
